Wagner by Diversitech - Wagner by Diversitech WG840463 Multi-Horsepower Direct Drive Furnace Blower Motor, DDFB Enclosure, 1/2, 1/3, 1/4, 1/5, 1/6 hp, 115 VAC, 60 Hz, 1 ph, 48 Frame, 1075 rpm Speed, Belly Band/Shaft Up/Down Mount
- Item #: WG840463
- Manufacturer: WG840463 selecatableMap $selecatableMap.size() \\ selectableItemList $selectableItemList.size()
- Brand Name: Wagner by Diversitech
- Min. Order Qty: 1
- Qty. Interval: 1
This Wagner® WG840463 Multiple Horsepower Direct Drive Furnace Blower Motor, 115V, 1075/4 Speed, 1/2HP MAX is specially designed to cover a range of applications. The motor is electrically reversible and features 36 in. leads to ease installation.
Wagner by Diversitech Direct Drive Furnace Blower Motor, Multi-Horsepower, Condenser Fan Motors, Fan & Blower Motors Application, 1/2, 1/3, 1/4, 1/5, 1/6 hp, 115 VAC, 7/6.7/4.4/3.2/2.4 A Full Load, 60 Hz Frequency, 1 ph, 1075 rpm Speed, 4 Speed, DDFB Enclosure, 48 Frame, 1/2 in Dia x 5 in L Shaft, Reversible Rotation, 1 Service Factor, Ball Bearing, Belly Band/Shaft Up/Down Mounting, 140 deg F, Insulation Class: Class B, 5.59 in Dia x 10.292 in L Dimensions
- Motor HP 1/3 HP
- Voltage 115V
- Motor RPM 1075 RPM
Catalog- Motors feature reversing plugs, extended thru bolts, 36 in leads and low power consumption
- Ball bearing design allows for greater heat endurance, improved performance, increased reliability, and enhanced motor life
- Extended mounting bolts provides easier installation in cramped spaces and allows the installer to start the threaded mounting nut quickly and efficiently
