Samsung WindFree™ Standard Multi-Split Indoor Unit, 208-230 V, 0.5 A, 50 W, 60 Hz, 1 ph Phase, 3 Fan Speeds, 18000 Btu/hr, 486 cfm Cooling, 623 cfm Heating, Flared Connection, R-32 Refrigerant, Tonnage: 1.5 ton, 41 dBA Sound Level, Wall Mounting, Polystyrene, White, 64 to 90 deg F, 8-7/16 in Overall Length, 41-9/16 in Overall Width, 11-3/4 in Overall Height, For Use With: FJM Multi-Zone Systems
- BTU 18K
- Refrigerant R-32
- Series WindFree Standard
- Indoor/Outdoor IDU
Submittal- The indoor unit shall feature WindFree™* mode, When activated in cooling mode the unit will close its louver and will disperse air into the space through thousands of micro-holes on the front of the indoor unit preventing cold air drafts on occupants
- The indoor unit shall have integral Wi-Fi capability as standard
- The outdoor unit shall provide 208/230V power to the indoor unit via 14 AWG X 3 interconnect power cable
- The indoor unit chassis shall be UL94 V0 with a galvanized steel mounting bracket
- The indoor unit shall have easy access to wire, pipe, and drain connections via the access panel on the bottom of the unit for simple installation and service
- The heat exchanger shall be mechanically bonded fin to copper tube
- Refrigerant flow shall be controlled by an electronic expansion valve at the outdoor unit
- The indoor fan shall be a single, antibacterial cross-flow type
- Three fan speeds and auto settings
- Automatic (motorized) vertical swing (up/down) and horizontal swing (left/ right) louvers
