Samsung - Samsung AR36BSHUMGMXCV Heat Pump Split System Outdoor Unit, 208 - 230 V, 5/16.8/19.1 A Cooling, 3/20/24 A Heating, Steel
- Item #: AR36BSHUMGMXCV
- Manufacturer: AR36BSHUMGMXCV selecatableMap $selecatableMap.size() \\ selectableItemList $selectableItemList.size()
- Brand Name: Samsung
- Min. Order Qty: 1
- Qty. Interval: 1
Samsung Heat Pump Split System Outdoor Unit, 208 - 230 V, 5/16.8/19.1 A Cooling, 3/20/24 A Heating, 125 W, 60 Hz, 1 ph Phase, 3 Fan Speeds, 40000 Btu/hr Heating, 36000 Btu/hr Cooling, 3532 cfm Condenser, 699 to 830 cfm Evaporator Heating CFM Rating, 9.5 EER Rating, 19.2 SEER, 8.5 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 5/8 in Suction Line, 35 A Fuse Rating, Inverter Drive, 52 dBA, 54 dBA Heating Sound Level, Wall Mounting, Steel, Finish: Galvanized/Powder-Coated, Gray, 4 to 75 deg F Heating Operating Temperature, 23 to 115 deg F Cooling Operating Temperature, 13 in Overall Length, 37 in Overall Width, 47-5/8 in Overall Height, Additional Information: RAC Classification, 2022 Version, Inverter R-410A HP Type, Max RAC Design
- Tonnage 4 Tons
- SEER Rating 19.2
Catalog.png){kind=link}
- The outdoor unit shall supply power to indoor unit via 14 AWG X 3 power wire
- High-voltage terminal block temperature sensor to disable unit in the event of power connection overheating
- Auto-restart after power loss
- Soft-start compressor minimizing current inrush
- All heat exchangers shall be mechanically bonded aluminum fin to copper tube
- The condensing unit heat exchanger salt spray test method: ASTM-B117-18 - the heat exchanger showed no unusual rust or corrosion development to 2,280 hours
- Three fan speed settings and auto setting
- Washable filter as standard
- Control wiring shall be 2 X 16 AWG
- Wireless controller included as standard
- Dual set temperature support when connected to MWR-WG00UN Advanced Wired Controller or central control options
