Ameristar™ - American Standard® A5AHC004A1D30A Multi-Position Air Handler, 24000 to 42000 Btu/hr BTU, 208-230 V, 3.9 A, 1/2 hp, 60 Hz
- Item #: A5AHC004A1D30A
- Manufacturer: A5AHC004A1D30A selecatableMap $selecatableMap.size() \\ selectableItemList $selectableItemList.size()
- Brand Name: Ameristar™
- Min. Order Qty: 1
- Qty. Interval: 1
Experience all-season comfort with this eco-friendly air handler, providing dependable operation year-round with a reduced environmental footprint.
American Standard® Multi-Position Air Handler, Model: A5AHC, 2 ton, 2.5 ton, 3 ton, 3.5 ton Nominal Capacity, 24000 to 42000 Btu/hr Cooling Capacity, 24000 to 42000 Btu/hr, 208-230 V, 3.9 A, 1/2 hp, 60 Hz, 1 ph Phase, Downflow, Horizontal, Upflow, NPT Connection, R-454B Refrigerant, 15 A Fuse Rating, 3 to 14 FPI, 5.5 sq-ft Face Area Coil, 3/4 in Connection, 3/8 in Liquid Line, 7/8 in Suction Line, 8 Speed, Constant Torque ECM Motor, Floor Mounting, Steel, Finish: Galvanized, 51-3/8 in H x 23-1/2 in W x 21-1/8 in D
- Tonnage 3 Ton
- Cooling Capacity 24000 to 42000 Btu/hr
- Suction Line Size 7/8 in
- Amperage Rating 3.9 A
- Voltage Rating 208-230 V
- Refrigerant Type R-454B
- Nominal Capacity 2 ton, 2.5 ton, 3 ton, 3.5 ton
- All-aluminum coil
- Factory-installed flow control to support ratings
- Fully insulated galvanized steel cabinet
- Multi-speed fan motors
- Assembled in Vidalia, Georgia
- Compatible with equipment using the newest refrigerant, R-454B, with a lower global warming potential (GWP)
