American Standard® - AccuLink™, ZZON Series, ZZONEPNLAC52ZA, Zoning Control Panels, 24 V ac, Mains Power Method
- Item #: ZZONEPNLAC52ZA
- Manufacturer: ZZONEPNLAC52ZB selecatableMap $selecatableMap.size() \\ selectableItemList $selectableItemList.size()
- Brand Name: American Standard®
- Min. Order Qty: 1
- Qty. Interval: 1
AccuLink™, Zone Expander Panel, ZZON Series, White, Screws Includes, Limited Warranty, Zoned Communicating System Suitable For Use With, LCD Display, Wire Connection, 24 V ac, 8 Number of Zones, Mains Power Method, W x 1.9 in D x 9.3 in H
- Type Zone Expander Panel
- Series ZZON
- Voltage Rating 24
- Suitable For Use With Zoned Communicating System
- Height 9.3
- Width 8
- Depth 1.9
- Color White
- Power Method Mains
- Connection Type Wire Connection
- Warranty Limited
- Display LCD
- Includes Screws
- Number of Zones 8
- Expands the maximum number of zones per system to eight
- Controls 24 Volt power open, power close modulating dampers
- Auto detects installed dampers
- Supports 2-wire (ZZSENSAL0400AA) and 3-wire (AZONE940) zone sensors
- Adjustable damper motor travel times of 15 to 60 seconds
- Requires field supplied 24 Volt power Supply
Application: Air Conditioner
