American Standard® - S9V2- 80K BTU Gold - 97% Two Stage Variable Speed- Upflow/Horizontal- 17.5
- Item #: S9V2B080U4VSAC
- Manufacturer: S9V2B080U4VSAC selecatableMap $selecatableMap.size() \\ selectableItemList $selectableItemList.size()
- Brand Name: American Standard®
- Min. Order Qty: 1
- Qty. Interval: 1
Maximum efficiency is provided with little noise by the patented VorticaTM II variable speed blower and variable speed draft inducer. Upflow/horizontal furnaces with the Energy Star label have an AFUE rating of 97%. In the summer, the Comfort-RTM enhanced dehumidification mode lowers the indoor humidity level. A newly designed cabinet base fits into smaller areas. main and secondary heat exchangers made of stainless steel cabinet insulation for silent operation
-Patented Vortica™ II variable speed blower and two speed draft inducer delivers maximum efficiency with very little sound
-Energy Star rated upflow/horizontal furnace is rated at 96% Annual Fuel Utilization Efficiency (AFUE)
-Comfort-R™ enhanced dehumidification mode reduces home humidity level in summer
-Re-designed cabinet platform to fit in tighter spaces
-Stainless steel primary and secondary heat exchanger
-Insulated cabinet for quiet operation
- Configuration Upflow, Horizontal
- Width B = 17.5"
- furnace efficiency 90%+
- Series S9V2B Series
- Tonnage 4 ton
- BTU Rating 80 K
- Stages 2 Stage
- Application Multi-Position
- AFUE Rating 97 %
- Cooling Capacity 4
- Amperage Rating 10.9 A
- Voltage Rating 115 V
- Variable speed blower motor
- Variable speed draft inducer
- Heavy gauge, two-tone powder-painted cabinet
- Increased dehumidification with Comfort-R™
