American Standard® - American Standard® TruComfort™ 5TEMCD04AV31DA Convertible Air Handler, 24000 to 42000 Btu/hr BTU, 1200 cfm, 208-230 V

  • Item #: 5TEMCD04AV31DA
  • Manufacturer: 5TEMCD04AV31DA
  • Brand Name: American Standard®
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
loading

American Standard® Convertible Air Handler, 24000 to 42000 Btu/hr Cooling Capacity, 24000 to 42000 Btu/hr, 208-230 V, 3.9 A, 60 Hz, 1 ph Phase, 1050 rpm Rotational Speed, 1200 cfm, 4-Way Poise, NPT Connection, R-454B Refrigerant, 15 A, 60 A Fuse Rating, 3/4 in Connection, 3/8 in Liquid Line, 7/8 in Suction Line, Variable Speed Motor, 51-3/8 in H x 23-1/2 in W x 21-1/8 in D

  • Series 5TEMC
  • Tonnage 3 Ton
  • Cooling Capacity 24000 to 42000 Btu/hr
  • Suction Line Size 7/8 in
  • Amperage Rating 3.9 A
  • Voltage Rating 208-230 V
  • Refrigerant Type R-454B
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/American_Standard_5TEMCD04AV31DA_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/American_Standard_5TEMCD04AV31DA_Specification_Sheet.pdf
  • Link™ Communicating or 24V control
  • Painted metal cabinet with captured foil face insulation
  • 2% or less air leakage
  • R-4.2 Insulating Value
  • Multi-Position UP/Down Flow, Horizontal Left /Right
  • ALL Aluminum Coil
  • Electric Heaters with polarized plug connections (sold as accessory)
  • R-454B Thermal Expansion Valve
  • Variable Speed ECM Motor
  • Low Voltage Pigtail Connections
  • Draw Through Design
  • Horizontal Drain Pan
  • Single Color
  • Fused 24V Power
  • 5 Year Base Limited Warranty
  • 10 Year Registered Limited Warranty
  • Optional extended warranty available
